The AEM Inc. MCI1206J122KT-T is a multilayer ceramic inductor designed for a wide range of high-frequency applications. As part of AEM's MCI series, this inductor offers a compact size and excellent performance characteristics. Its robust construction ensures reliability and stability in demanding electronic circuits.

Applications

• RF circuits
• Wireless communication devices
• Mobile phones
• Bluetooth devices
• GPS modules
• High-frequency filters
• Matching networks

Features

• Multilayer ceramic construction
• Compact 1206 package size (3.2mm x 1.6mm)
• High self-resonant frequency
• Excellent Q factor
• Surface mount technology (SMT)
• Operating temperature range: -55°C to +125°C
• Inductance value: 1.2uH
• Tolerance: ±10%

Benefits

• Miniaturization: The small 1206 package allows for compact circuit designs, saving valuable board space.
• High Performance: High Q factor and self-resonant frequency ensure optimal performance in high-frequency applications.
• Reliability: The ceramic construction provides excellent stability and reliability in harsh environments.
• Easy Assembly: SMT design enables automated assembly, reducing manufacturing costs.
• Versatility: Suitable for a wide range of applications, including RF, wireless, and mobile devices.

The MCI1206J122KT-T inductor's technical specifications include an inductance value of 1.2uH with a tolerance of ±10%. It features a high self-resonant frequency, essential for effective operation in high-frequency circuits. Constructed with multiple layers of ceramic material, the inductor offers excellent electrical characteristics and mechanical strength. Its surface mount technology (SMT) design facilitates easy integration into automated assembly processes. The operating temperature range spans from -55°C to +125°C, ensuring stable performance under various environmental conditions. Due to its compact size and high-performance capabilities, it is a preferred choice for designers aiming to minimize board space without compromising signal integrity.
