Same model may have multiple batches, images only for reference.

AMSRB1-7805JZ

Name: AMSRB1-7805JZ
Brand: AIMTEC
SKU: 1342274
Availability: InStock
Rating: 4.85 (5 reviews)

Get a Quote

Part No	AMSRB1-7805JZ
Manufacturer	AIMTEC
Catalog	Power Supplies Board Mount DCDC Converters
Description	DC DC CONVERTER 5V 5W / Non-Isolated PoL Module DC DC Converter 1 Output 5V 1A 8V - 36V Input
Datasheet	AMSRB1-7805JZ Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Power Supplies - Board Mount - DC DC Converters
Mfr	aimtec
Series	AMSRB1-78JZ
Package	Tube
Type	Non-Isolated PoL Module
Number of Outputs	1
Voltage - Input (Min)	8V
Voltage - Input (Max)	36V
Voltage - Output 1	5V
Current - Output (Max)	1A
Power (Watts)	5 W
Applications	ITE (Commercial)
Temperature Range - Operating	-40°C ~ 85°C (With Derating)
Efficiency	93%
Mounting Type	Through Hole
Package / Case	3-SIP Module
Size / Dimension	0.46" L x 0.32" W x 0.41" H (11.6mm x 8.0mm x 10.4mm)
Supplier Device Package	3-SIP
Base Product Number	AMSRB
Standard Package	1
MSL Level	1 (Unlimited)
ECCN	EAR99
HTSUS	8504.40.9580
Win Source Part Number	1342274-AMSRB1-7805JZ
Ultra Librarian 3D Model	Ultra Librarian AMSRB1-7805JZ CAD Model

Alternative Products

Description

The AMSRB1-78JZ series non-isolated PoL module from Aimtec is a high-quality electronic component suitable for use in a wide range of applications.

Series: AMSRB1-78JZ
Package: 3-SIP Module
Standard Package: 1
Size/Dimension: 0.46" L x 0.32" W x 0.41" H (11.6mm x 8.0mm x 10.4mm)
Power Output: 5W
Output Current: 1A @ 5V
Input Voltage Range: 8V to 36V
Efficiency: 93%
Operating Temperature: -40°C to 85°C (with derating)
MSL Level: 1 (Unlimited)
HTSUS: 8504.40.9580
Manufacturer: Aimtec
