AOD256 Real Image AOD256 Real Image
Same model may have multiple batches, images only for reference.
AOD256 Real Image AOD256 Real Image
AOD256 Real Image AOD256 Real Image
Same model may have multiple batches, images only for reference.

AOD256

Part No AOD256
Manufacturer Alpha & Omega Semiconductor Inc.
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET N-CH 150V 19A TO252
Datasheet
AOD256 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Alpha & Omega Semiconductor Inc.
Packaging Reel - TR
Status Active
Polarity N-Channel
Technology MOSFET
Drain-Source Breakdown Voltage 150V
Continuous Drain Current at 25°C 3A (Ta), 19A (Tc)
Drive Voltage (Max Rds On, Min Rds On) 4.5V, 10V
Gate-Source Threshold Voltage 2.8V @ 250μA
Max Gate Charge 22nC @ 10V
Max Input Capacitance 1165pF @ 75V
Maximum Gate-Source Voltage ±20V
Power Dissipation (Max) 2.5W (Ta), 83W (Tc)
Maximum Rds On at Id,Vgs 85 mOhm @ 10A, 10V
Temperature Range - Operating -55°C to 175°C (TJ)
Mounting SMD (SMT)
Case / Package TO-252, (D-Pak)
Dimension TO-252-3, DPak (2 Leads + Tab), SC-63
Win Source Part Number 104990-AOD256
Family Name AOD256
Introduction Date July 25, 2012
ECCN EAR99
Country of Origin China
Halogen Free Compliant
Estimated EOL Date 2019
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian AOD256 CAD Model

Description

Product Overview

The AOD256 is designed with eco-friendly technologies, making it a preferred option for green energy solutions. It delivers outstanding efficiency while minimizing environmental impact.

Features and Benefits

  • Eco-Friendly: Manufactured using sustainable materials and processes.
  • High Efficiency: Maximizes energy use, reducing waste.
  • Reliable Performance: Ensures stable operation in diverse applications.

Applications

  • Solar power systems
  • Wind energy converters
  • Electric vehicles
  • Eco-friendly electronics

Additional Details

The AOD256 is a testament to innovative engineering, providing efficient solutions while supporting environmental sustainability objectives.
