AOD2922 Real Image AOD2922 Real Image
Same model may have multiple batches, images only for reference.
AOD2922 Real Image AOD2922 Real Image
AOD2922 Real Image AOD2922 Real Image
Same model may have multiple batches, images only for reference.

AOD2922

Part No AOD2922
Manufacturer Alpha & Omega Semiconductor Inc.
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET N-CH 100V 3.5A TO252
Datasheet
AOD2922 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Alpha & Omega Semiconductor Inc.
Packaging Reel - TR
Status Active
Polarity N-Channel
Technology MOSFET
Drain-Source Breakdown Voltage 100V
Continuous Drain Current at 25°C 3.5A (Ta), 7A (Tc)
Drive Voltage (Max Rds On, Min Rds On) 4.5V, 10V
Gate-Source Threshold Voltage 2.7V @ 250μA
Max Gate Charge 10nC @ 10V
Max Input Capacitance 310pF @ 50V
Maximum Gate-Source Voltage ±20V
Power Dissipation (Max) 5W (Ta), 17W (Tc)
Maximum Rds On at Id,Vgs 140 mOhm @ 5A, 10V
Temperature Range - Operating -55°C to 175°C (TJ)
Mounting SMD (SMT)
Case / Package TO-252, (D-Pak)
Dimension TO-252-3, DPak (2 Leads + Tab), SC-63
Win Source Part Number 009789-AOD2922
Family Name AOD2922
Introduction Date October 29, 2013
ECCN EAR99
Country of Origin China
Halogen Free Compliant
Estimated EOL Date 2023
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian AOD2922 CAD Model

Description

AOD2922 MOSFET Transistor

The AOD2922 is a high-performance MOSFET transistor ideal for various electronic applications. With its efficient design and robust construction, it offers outstanding power handling and excellent thermal stability, making it suitable for a wide range of demanding projects.

  • DC-DC converters
  • Motor drives
  • Switching regulators
  • Audio amplifiers

Features and Benefits:

  • Low on-resistance for reduced power loss
  • High-speed switching capability for improved efficiency
  • Enhanced thermal performance for reliable operation

Due to its compact size and reliable performance, the AOD2922 is a preferred choice for engineers seeking to optimize space without compromising on power handling capability.
