AONS62922 Alpha & Omega Semiconductor Inc. AONS62922 real image23447
Same model may have multiple batches, images only for reference.
AONS62922 Alpha & Omega Semiconductor Inc. AONS62922 real image23447
AONS62922 Alpha & Omega Semiconductor Inc. AONS62922 real image23447
Same model may have multiple batches, images only for reference.

AONS62922

Part No AONS62922
Manufacturer Alpha & Omega Semiconductor Inc.
Catalog Misc Products
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Uncategorized
Manufacturer Alpha & Omega Semiconductor Inc.
Popularity Low
Supply and Demand Status Balance
Win Source Part Number 843133-AONS62922
Package Tape & Reel (TR);Cut Tape (CT)
Product Status Active
FET Type N-Channel
Technology MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss) 120V
Current - Continuous Drain (Id) @ 25°C 22A (Ta), 85A (Tc)
Drive Voltage (Max Rds On, Min Rds On) 4.5V, 10V
Rds On (Max) @ Id, Vgs 7 mOhm @ 20A, 10V
Vgs(th) (Max) @ Id 2.4V @ 250µA
Gate Charge (Qg) (Max) @ Vgs 65 nC @ 10 V
Vgs (Max) ±20V
Input Capacitance (Ciss) (Max) @ Vds 3295 pF @ 60 V
Power Dissipation (Max) 7.3W (Ta), 215W (Tc)
Operating Temperature -55°C ~ 150°C (TJ)
Grade -
Mounting Type Surface Mount
Supplier Device Package 8-DFN (5x6)
Package / Case 8-PowerSMD, Flat Leads
Ultra Librarian 3D Model Ultra Librarian AONS62922 CAD Model

Description

The Alpha & Omega Semiconductor Inc. 843133-AONS62922 is an electronic component that is categorized as uncategorized.

  • Supply and Demand: Balanced
  • Manufacturer: Alpha & Omega Semiconductor Inc.
