AZ2150-1A-24DE ZETTLER Electronics
Same model may have multiple batches, images only for reference.

AZ2150-1A-24DE

Part No AZ2150-1A-24DE
Manufacturer American Zettler, Inc.
Catalog Power Relays, Over 2 Amps
Description 40A POWER RELAY / General Purpose Relay SPST-NO (1 Form A) 24VDC Coil Through Hole
Datasheet
AZ2150-1A-24DE Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Relays - Power Relays, Over 2 Amps
Mfr American Zettler, Inc.
Series AZ2150
Package Box
Product Status Active
Mounting Type Through Hole
Coil Voltage 24VDC
Contact Form SPST-NO (1 Form A)
Contact Rating (Current) 40 A
Switching Voltage 300VAC, 30VDC - Max
Coil Current 36.4 mA
Coil Type Non Latching
Termination Style PC Pin
Seal Rating Sealed - Fully
Coil Insulation Class B
Must Operate Voltage 18 VDC
Must Release Voltage 2.4 VDC
Operate Time 12 ms
Release Time 5 ms
Temperature Range - Operating -55°C ~ 85°C
Contact Material Silver Cadmium Oxide (AgCdO)
Relay Type General Purpose
Coil Resistance 660 Ohms
Standard Package 40 pcs
Win Source Part Number 567539-AZ2150-1A-24DE
Ultra Librarian 3D Model Ultra Librarian AZ2150-1A-24DE CAD Model

Description

The AZ2150-1A-24DE is a SPST-NO (1 Form A) power relay from American Zettler, Inc.

  • Series: AZ2150 series
  • Coil Voltage: 24VDC
  • Contact Rating: 40A
  • Switching Voltage: 300VAC, 30VDC maximum
  • Operate Time: 12ms
  • Release Time: 5ms
  • Performance: Provides reliable performance for general purpose applications.
  • Termination Style: PC Pin
  • Mounting Type: Through Hole
  • Sealing: Sealed Fully
  • Temperature Range: -55°C to 85°C
  • Standard Package: 40 pcs
  • Applications: Widely used in various electronic devices and systems.
  • Coil Resistance: 660 Ohms
  • Coil Current: 36.4 mA
  • Contact Material: Silver Cadmium Oxide (AgCdO)
