AZ7555-1A-24DSKE Real Image
Same model may have multiple batches, images only for reference.

AZ7555-1A-24DSKE

Part No AZ7555-1A-24DSKE
Manufacturer American Zettler, Inc.
Catalog Power Relays, Over 2 Amps
Description RELAY GEN PURPOSE SPST 20A 24V / General Purpose Relay SPST-NO (1 Form A) 24VDC Coil Through Hole
Datasheet
AZ7555-1A-24DSKE Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Relays>Power Relays, Over 2 Amps
Mfr American Zettler
Package Tray
Mounting Type Through Hole
Coil Voltage 24VDC
Contact Form SPST-NO (1 Form A)
Contact Rating (Current) 20 A
Switching Voltage 277VAC, 30VDC - Max
Coil Current 21.8 mA
Coil Type Non Latching
Termination Style PC Pin
Seal Rating Sealed - Fully
Must Operate Voltage 18 VDC
Must Release Voltage 2.4 VDC
Operate Time 20 ms
Release Time 8 ms
Temperature Range - Operating -40°C ~ 85°C
Contact Material Silver Tin Oxide (AgSnO)
Relay Type General Purpose
Coil Resistance 1.1 kOhms
MSL Level 1 (Unlimited)
ECCN EAR99
HTSUS 8536.41.0050
Other Names 3385-AZ7555-1A-24DSKE
Standard Package 1,000
Win Source Part Number 1205953-AZ7555-1A-24DSKE
Ultra Librarian 3D Model Ultra Librarian AZ7555-1A-24DSKE CAD Model

Description

The AZ7555-1A-24DSKE is a power relay manufactured by American Zettler.

  • Category: Power Relays over 2 Amps
  • Contact Form: SPST-NO (1 Form A)
  • Contact Material: Silver Tin Oxide (AgSnO)
  • Coil Voltage: 24VDC
  • Contact Rating (Current): 20A
  • Switching Voltage: 277VAC and 30VDC - Max
  • Release Time: 8ms
  • Operating Temperature Range: -40°C ~ 85°C
