Same model may have multiple batches, images only for reference.
AZ7709T-1AE-24DSEF Real Image
Same model may have multiple batches, images only for reference.

AZ7709T-1AE-24DSEF

Part No AZ7709T-1AE-24DSEF
Manufacturer American Zettler, Inc.
Catalog Power Relays, Over 2 Amps
Description RELAY GEN PURPOSE SPST 5A 24V / General Purpose Relay SPST-NO (1 Form A) 24VDC Coil Through Hole
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Relays>Power Relays, Over 2 Amps
Mfr American Zettler
Package Tray
Mounting Type Through Hole
Coil Voltage 24VDC
Contact Form SPST-NO (1 Form A)
Contact Rating (Current) 5 A
Switching Voltage 250VAC, 30VDC - Max
Coil Current 8.6 mA
Coil Type Non Latching
Termination Style PC Pin
Seal Rating Sealed - Fully
Coil Insulation Class F
Must Operate Voltage 18 VDC
Must Release Voltage 1.2 VDC
Operate Time 8 ms
Release Time 4 ms
Temperature Range - Operating -40°C ~ 105°C
Contact Material Silver Tin Oxide (AgSnO)
Relay Type General Purpose
Coil Resistance 2.8 kOhms
MSL Level 1 (Unlimited)
ECCN EAR99
HTSUS 8536.41.0020
Other Names 3385-AZ7709T-1AE-24DSEF
Standard Package 1,000
Win Source Part Number 1230073-AZ7709T-1AE-24DSEF
Ultra Librarian 3D Model Ultra Librarian AZ7709T-1AE-24DSEF CAD Model

Description

The American Zettler Relay is a general-purpose non-latching relay that features a SPST-NO contact form with a 1 Form A configuration.

  • Type: General Purpose, Non-Latching
  • Contact Form: SPST-NO (1 Form A)
  • Switching Voltage: 250VAC, 30VDC
  • Contact Rating (Maximum): 5A
  • Coil Voltage: 24VDC
  • Coil Resistance: 2.8 kOhms
  • Coil Current: 8.6 mA
  • Seal Rating: Fully Sealed
  • Mounting Type: Through-Hole
  • Operating Temperature: -40°C to 105°C
  • Application: Power Relays (over 2 Amps)
