Same model may have multiple batches, images only for reference.
10123422-101LF Real Image
Same model may have multiple batches, images only for reference.

10123422-101LF

Part No 10123422-101LF
Manufacturer Amphenol
Catalog Backplane Connectors
Description CONN RCPT HI SPEED 150P EDGE MT  /  150 Connector Receptacle, Female Sockets Board Edge, Through Hole, Right Angle Natural High Speed
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Connectors, Interconnects>Backplane Connectors - Specialized
Mfr Amphenol ICC (FCI)
Series Airmax VS2™
Package Tube
Connector Usage Daughtercard
Connector Type Receptacle, Female Sockets
Connector Style High Speed
Number of Positions 150
Number of Positions Loaded All
Pitch 0.079" (2.00mm)
Number of Columns 10
Mounting Type Board Edge, Through Hole, Right Angle
Termination Press-Fit
Contact Finish Gold
Color Natural
Current Rating (Amps) 0.5A per Contact
Material Flammability Rating UL94 V-0
Temperature Range - Operating -55°C ~ 85°C
Voltage Rating 50VAC
Base Product Number 10123422
MSL Level 1 (Unlimited)
REACH Status REACH Affected
ECCN EAR99
HTSUS 8536.69.4040
Other Names 10123422-101LF-ND,609-4753
Standard Package 29
Win Source Part Number 1015102-10123422-101LF
Ultra Librarian 3D Model Ultra Librarian 10123422-101LF CAD Model

Description

The AMPHENOL 1015102-10123422-101LF is an Airmax VS2™ connector with 150 positions and a pitch of 0.079" (2.00mm). The manufacturer is Amphenol ICC (FCI).

  • Color: natural
  • Connector Type: receptacle, female sockets
  • Positions Loaded: All
  • Termination: press-fit
  • Contact Finish: gold
  • Package: tube
  • Connector Style: high speed
  • Voltage Rating: 50VAC
  • Material Flammability Rating: UL94 V-0
  • Standard Package: 29
  • Connector Usage: daughtercard
  • Number of Columns: 10
  • Mounting Type: board edge, through hole, right angle
  • Temperature Range for Operation: -55°C ~ 85°C
  • ECCN: EAR99
  • MSL Level: 1 (unlimited)
  • Current Rating: 0.5A per contact
  • REACH Status: REACH affected
  • HTSUS: 8536.69.4040
  • Other Names: 10123422-101LF-ND and 609-4753
