Same model may have multiple batches, images only for reference.
20021311-00010T4LF Real Image
Same model may have multiple batches, images only for reference.

20021311-00010T4LF

Part No 20021311-00010T4LF
Manufacturer Amphenol
Catalog Circular Connectors - Housings
Description CONN RCPT 10POS 0.05 GOLD PCB  /  10 Position Receptacle Connector 0.050" (1.27mm) Through Hole Gold
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Connectors, Interconnects>Rectangular Connectors - Headers, Receptacles, Female Sockets
Mfr Amphenol ICC (FCI)
Series Minitek127® 1.27mm
Package Tube
Connector Type Receptacle
Contact Type Female Socket
Style Board to Board
Number of Positions 10
Number of Positions Loaded All
Pitch - Mating 0.050" (1.27mm)
Number of Rows 2
Row Spacing - Mating 0.050" (1.27mm)
Mounting Type Through Hole
Termination Solder
Fastening Type Push-Pull
Contact Finish - Mating Gold
Contact Finish Thickness - Mating 10.0µin (0.25µm)
Insulation Color Black
Insulation Height 0.173" (4.40mm)
Contact Length - Post 0.094" (2.40mm)
Temperature Range - Operating -40°C ~ 105°C
Material Flammability Rating UL94 V-0
Contact Finish - Post Tin
Applications General Purpose, Industrial, Telecommunications
Insulation Material Plastic
Contact Shape Square
Contact Material Phosphor Bronze
Contact Finish Thickness - Post 100.0µin (2.54µm)
Base Product Number 20021311
MSL Level 1 (Unlimited)
REACH Status REACH Affected
ECCN EAR99
HTSUS 8536.69.4040
Other Names 609-3754,10122289-310000TLF,2002131100010T4LF
Standard Package 86
Win Source Part Number 1223061-20021311-00010T4LF
Ultra Librarian 3D Model Ultra Librarian 20021311-00010T4LF CAD Model

Description

The Minitek127® 1.27mm series connector is a rectangular connector designed for board-to-board applications.

  • Connector Type: Receptacle
  • Positions: 10
  • Rows: 2
  • Pitch: 0.050 inches (1.27mm)
  • Contact Material: Phosphor bronze
  • Contact Finish (Mating): Gold
  • Contact Finish (Post): Tin
  • Insulation Material: Plastic
  • Color: Black
  • Flammability Rating: UL94 V-0
  • Mounting: Through-hole
  • Temperature Range: -40°C to 105°C
  • Package: Tube
  • Standard Package: 86 units
  • Alternative Part Number: 2002131100010T4LF
