Same model may have multiple batches, images only for reference.
95157-120VLF Real Image
Same model may have multiple batches, images only for reference.

95157-120VLF

Part No 95157-120VLF
Manufacturer Amphenol
Catalog Circular Connectors - Housings
Description CONN HEADER SMD 20POS 2.54MM  /  Connector Header Surface Mount 20 position 0.100" (2.54mm)
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Connectors, Interconnects>Rectangular Connectors - Headers, Male Pins
Mfr Amphenol ICC (FCI)
Series BERGSTIK® II
Package Tape & Reel (TR)
Connector Type Header
Contact Type Male Pin
Pitch - Mating 0.100" (2.54mm)
Number of Positions 20
Number of Rows 2
Row Spacing - Mating 0.100" (2.54mm)
Number of Positions Loaded All
Style Board to Board
Shrouding Unshrouded
Mounting SMD (SMT)
Termination Solder
Fastening Type Push-Pull
Contact Length - Mating 0.230" (5.84mm)
Insulation Height 0.100" (2.54mm)
Contact Shape Square
Contact Finish - Mating Gold
Contact Finish Thickness - Mating 30.0µin (0.76µm)
Contact Finish - Post Tin
Contact Material Phosphor Bronze
Features Pick and Place
Temperature Range - Operating -65°C ~ 130°C
Material Flammability Rating UL94 V-0
Insulation Color Black
Current Rating (Amps) 3A
Base Product Number 95157
MSL Level 1 (Unlimited)
REACH Status REACH Affected
ECCN EAR99
HTSUS 8536.69.4040
Standard Package 185
Win Source Part Number 995236-95157-120VLF
Ultra Librarian 3D Model Ultra Librarian 95157-120VLF CAD Model

Description

The Amphenol ICC (FCI) BERGSTIK® II series rectangular connector is a header connector with 20 positions.

  • Positions: 20
  • Fastening Type: Push-Pull
  • Contact Material: Phosphor Bronze
  • Contact Finish: Gold
  • Mounting: SMD (SMT)
  • Shrouding: Unshrouded
  • Pitch: 0.100" (2.54mm)
  • Contact Finish Thickness: 30.0µin (0.76µm)
  • Current Rating: 3A
  • Temperature Range: -65°C to 130°C
