AD7606BSTZ-6

Part No AD7606BSTZ-6
Manufacturer Analog Devices Inc.
Catalog Data Acquisition - ADCs/DACs - Special Purpose
Description IC DAS W/ADC 16BIT 6CH 64LQFP
Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Analog Devices Inc.
Packaging Tray
Status Active
Type Data Acquisition System (DAS), ADC
Resolution (Bits) 16 b
Sampling Rate 200k
Data Interface DSP, MICROWIRE, Parallel, QSPI, Serial, SPI
Voltage Supply Source Analog and Digital
Supply Voltage - Operating 2.3 V to 5.25 V, 4.75 V to 5.25 V
Temperature Range - Operating -40°C to 85°C
Mounting SMD (SMT)
Case / Package 64-LQFP (10x10)
Win Source Part Number 077054-AD7606BSTZ-6
Family Name AD7606
Introduction Date February 08, 2010
ECCN EAR99
Country of Origin China
Halogen Free Compliant
Estimated EOL Date 2028
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Application Field Used in Power Management, Motor Drive & Control, Sensing & Instrumentation, Automation & Process Control
Ultra Librarian 3D Model Ultra Librarian AD7606BSTZ-6 CAD Model

Description

AD7606BSTZ-6 Data Acquisition System

The AD7606BSTZ-6 is a high-performance data acquisition system-on-a-chip from Analog Devices Inc., designed to cater to the rigorous demands of industrial and instrumentation applications. This robust 16-bit ADC (Analog-to-Digital Converter) offers eight fully differential or 15 pseudo-differential input channels, providing the versatility needed for various signal configurations.

At the heart of the AD7606BSTZ-6 is its simultaneous sampling feature, which allows all channels to capture data at the same time, thereby preserving the relative timing information of the signals. This is particularly important in applications such as motor control, where phase relationships must be accurately maintained. With a sampling rate of up to 200 kSPS (kilo-samples per second), this device ensures high-speed performance without compromising on accuracy.

One of the key features of the AD7606BSTZ-6 is its user-selectable input ranges. Users can choose between ±5 V and ±10 V, providing flexibility in accommodating different signal levels. This feature, coupled with the device's overvoltage protection of up to ±16.5 V for all analog inputs, ensures reliable performance even in electrically noisy environments or in the presence of unexpected signal spikes.

The integrated analog input clamp protection, on-chip oversampling, and digital filter all contribute to the AD7606BSTZ-6's ability to deliver clean, precise data. The digital filter in particular helps to reduce the noise and improve the signal-to-noise ratio, which is critical for high-precision measurements.

For ease of interfacing with microprocessors or DSPs, the AD7606BSTZ-6 features a parallel interface with a dedicated BUSY indicator. This allows for straightforward integration into existing systems. The device is packaged in a compact 64-LQFP (Low-Profile Quad Flat Package), making it suitable for space-constrained applications.

In summary, the AD7606BSTZ-6 from Analog Devices Inc. is a versatile, high-precision data acquisition system that is ideal for a wide range of industrial and instrumentation applications. Its combination of simultaneous sampling, flexible input ranges, and robust protection features make it a reliable choice for engineers and designers seeking accurate and consistent data capture.
