Product Overview: AD780BR by Analog Devices Inc.

The AD780BR is a precision voltage reference component from the renowned manufacturer Analog Devices Inc., known for its high-quality electronic components. This device offers a unique combination of high accuracy, low noise, and long-term stability, making it an excellent choice for high-end applications that require a precise reference voltage.

Key Features

• Precision Voltage: The AD780BR provides a stable and precise output voltage of 2.5V or 3.0V, selectable by the user. This feature ensures versatility across different applications that require different reference voltages.
• High Accuracy: With an initial accuracy of ±0.1%, the AD780BR stands out for its ability to deliver precise voltage without significant deviation.
• Low Temperature Coefficient: The device boasts a low temperature coefficient of 10 ppm/°C max, which means its output voltage remains consistent across a wide temperature range.
• Low Noise: It exhibits exceptionally low noise performance, with a noise level of just 1 µV p-p/V, which is critical for sensitive electronic applications.
• Long-Term Stability: The AD780BR offers excellent long-term stability, ensuring that its performance does not degrade significantly over time.
• Wide Supply Range: It can operate with a supply range from 4.0V to 36V, providing flexibility in system design and compatibility with various power supplies.
• No External Components Required: This voltage reference operates effectively without the need for external capacitors, simplifying design and reducing the overall component count.

Applications

The AD780BR is ideal for high-precision applications such as:

• Precision data converters
• Portable instrumentation
• Medical devices
• Industrial process control systems
• Battery-powered and automotive systems

With its superior performance and reliability, the AD780BR from Analog Devices Inc. is an exceptional choice for engineers and designers seeking a top-tier voltage reference for their critical applications. Its combination of features ensures that it can meet the stringent requirements of even the most demanding precision electronic systems.
