AD7849BRZ-REEL

Part No AD7849BRZ-REEL
Manufacturer Analog Devices Inc.
Catalog Data Acquisition - Digital to Analog Converters (DAC)
Description IC DAC 16BIT V-OUT 20SOIC / Serial Input, 14-Bit/16-Bit DAC
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Manufacturer Analog Devices Inc.
Packaging Reel
Number of Bits 16
Number of D/A Converters 1
Settling Time 10μs (Typ)
Output Type Voltage - Buffered
Differential Output No
Data Interface SPI
Reference Type External
Voltage - Supply, Analog ±14.25V ~ 15.75V
Voltage - Supply, Digital 5V
INL/DNL (LSB) ±16 (Maximum), ±0.9 (Maximum)
Architecture String DAC
Temperature Range - Operating -40°C ~ 85°C
Manufacturer Package 20-SOIC
Supplier Device Package 20-SOIC
Mounting Style SMD
Part Number Series AD7849
Manufacturer Pack Quantity 1,000
MSL Level 3 (168 Hours)
Popularity Medium
Supply and Demand Status Balance
Win Source Part Number 805794-AD7849BRZ-REEL
Ultra Librarian 3D Model Ultra Librarian AD7849BRZ-REEL CAD Model

Description

Product Overview: AD7849BRZ-REEL

The AD7849BRZ-REEL is a high-performance, digital-to-analog converter (DAC) from Analog Devices Inc., renowned for its precision electronic components. This particular model is packaged in a convenient reel, making it suitable for high-volume production and automated assembly processes.

Key Features

  • Resolution: The AD7849 features a 14-bit resolution, providing fine granularity and high precision in analog output.
  • Interface: It boasts a serial interface which simplifies the connections to microprocessors and microcontrollers, reducing the complexity of the circuit design and the number of required I/O lines.
  • Settling Time: With a fast settling time, this DAC quickly reaches a stable output after a change in input data, which is critical for dynamic applications.
  • Power Supply: It operates on a single +5V power supply, minimizing power consumption and making it compatible with most standard digital systems.
  • Package: The device comes in a compact SOIC package, which is ideal for space-constrained applications.
  • Temperature Range: The AD7849 is designed to operate over the industrial temperature range, ensuring reliable performance under varying environmental conditions.

Applications

The versatility of the AD7849BRZ-REEL allows it to be used in a wide array of applications, including:

  • Industrial automation and process control
  • Data acquisition systems
  • Digital signal processing
  • Medical instrumentation
  • Automotive systems

Quality and Reliability

Analog Devices Inc. is known for its commitment to quality, and the AD7849BRZ-REEL is no exception. It is fabricated using advanced IC manufacturing techniques to ensure high reliability and performance consistency. Users can trust this DAC to deliver accurate and stable analog outputs for their critical applications.

For detailed specifications, application notes, and support resources, customers are encouraged to visit the official Analog Devices website or contact their local sales representative.
