Product Overview: AD7982BRMZ

The AD7982BRMZ is a high-precision, 18-bit, PulSAR® analog-to-digital converter (ADC) offered by Analog Devices Inc., a leading global manufacturer of high-performance integrated circuits used in analog and digital signal processing applications. This ADC is part of their PulSAR family of products, which are known for their exceptional accuracy and low power consumption, making them ideal for a wide range of applications including medical instruments, industrial control systems, and data acquisition devices.

Key Features

• Resolution: The AD7982BRMZ boasts an impressive 18-bit resolution, providing highly accurate digital representations of analog signals.
• Sampling Rate: With a maximum sampling rate of 1 MSPS (million samples per second), this ADC is capable of capturing fast-changing signals without sacrificing accuracy.
• Low Power Consumption: Designed for power-sensitive applications, it operates with a typical power consumption of just 7 mW at 1 MSPS, which can be reduced to 1 µW in standby mode.
• Input Voltage Range: It features a true differential analog input range of ±V REF, accommodating a wide variety of signal amplitudes.
• Interface: The device includes a serial peripheral interface (SPI) that ensures easy integration with microcontrollers and digital systems.
• Package: Housed in a compact 10-lead MSOP (Mini Small Outline Package), the AD7982BRMZ is designed for space-constrained applications.

Applications

The versatility of the AD7982BRMZ allows it to be used in various high-precision applications. In the medical field, it can be found in imaging systems and patient monitoring equipment. For industrial use, it is ideal for process control, instrumentation, and energy management systems. Additionally, its precision and speed make it suitable for data acquisition systems, where accurate and rapid conversion of analog signals to digital data is critical.

Quality and Reliability

Analog Devices Inc. is committed to providing high-quality products. The AD7982BRMZ is built to meet rigorous standards, ensuring reliable performance in even the most demanding environments. Customers can trust in the durability and consistency of this ADC for their critical applications.
