AD822BRZ

Part No AD822BRZ
Manufacturer Analog Devices Inc.
Catalog Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
Description IC OPAMP GP 1.9MHZ RRO 8SOIC
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Manufacturer Analog Devices Inc.
Standard Package 98
Category Integrated Circuits(ICs)
Family Linear - Amplifiers - Instrumentation OP Amps Buffer Amps
Packaging Tube
Amplifier Type General Purpose
Number of Circuits 2
Output Type Rail-to-Rail
Slew Rate 3 V/µs
Gain Bandwidth Product 1.9MHz
-3db Bandwidth 1.9MHz
Current - Input Bias 2pA
Voltage - Input Offset 300µV
Current - Supply 1.4mA
Current - Output / Channel 20mA
Voltage - Supply Single/Dual (±) 3 V ~ 36 V ±1.5 V ~ 18 V
Operating Temperature Range -40°C ~ 85°C
Mounting Style SMD/SMT
Package 8-SOIC (0.154" 3.90mm Width)
Manufacturer Device Package 8-SOIC
Catalog General Purpose
Win Source Part Number 086866-AD822BRZ
Family Name AD822
Introduction Date June 24, 1997
ECCN EAR99
Country of Origin Malaysia
Halogen Free Compliant
Estimated EOL Date 2027
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Ultra Librarian 3D Model Ultra Librarian AD822BRZ CAD Model

Description

The AD822BRZ is a high-performance, low-power operational amplifier from the esteemed manufacturer Analog Devices Inc. This precision op-amp is designed for a wide range of applications, including battery-powered devices, due to its low power consumption and wide supply voltage range. Its versatility makes it an ideal choice for professionals in the electronics field looking for a reliable amplifier that delivers consistent performance.

Key Features:

  • Single-Supply Operation: The AD822BRZ is capable of operating from a single supply ranging from +3 V to +36 V, or dual supplies of ±1.5 V to ±18 V, providing flexibility in various circuit configurations.
  • Low Power Consumption: With a quiescent current of just 800 µA per amplifier, the AD822BRZ is optimized for battery-powered applications, helping to extend the life of portable devices.
  • High Output Drive Capacity: Capable of driving 10 kΩ loads to within 1.2 V of the supply rails, and 600 Ω loads to within 2.5 V, the AD822BRZ is suitable for driving heavier loads without sacrificing performance.
  • Rail-to-Rail Output Swing: The output stage of the AD822BRZ allows for a rail-to-rail output swing, ensuring maximum dynamic range especially in low supply voltage applications.
  • Low Input Bias Current: With an input bias current of only 1 pA, the AD822BRZ is an excellent choice for applications requiring high impedance sensors.
  • Low Offset Voltage: The device features a low offset voltage of 1 mV, which maintains the accuracy of the signal processing chain.

Applications:

  • Portable and battery-powered equipment
  • Medical instrumentation
  • Sensor signal conditioning
  • Audio and video signal processing
  • Data acquisition systems
  • Active filters
  • Buffer and amplifier circuits

The AD822BRZ comes in a robust 8-lead SOIC package, ensuring ease of integration into a wide range of electronic assemblies. Its combination of features makes it an excellent general-purpose op-amp for designers who require both accuracy and power efficiency in their applications.

With its strong feature set and reliable performance, the AD822BRZ operational amplifier from Analog Devices Inc. is a top choice for engineers and designers who demand the best in their electronic components.
