Product Overview: ADG5409BRUZ-REEL7

The ADG5409BRUZ-REEL7 is a high-performance, monolithic CMOS device from Analog Devices Inc. that offers a robust solution for routing and switching applications. This product is part of the renowned ADG5409 series and is well-suited for systems that require high reliability and durability.

Key Features

• Switch Configuration: The ADG5409BRUZ-REEL7 features a 4-channel differential 4:1 multiplexer, which provides efficient signal routing for complex systems.
• Low On Resistance: With a typical on resistance of just 4.5 ohms, this device ensures minimal signal attenuation and distortion, preserving signal integrity.
• Single Supply Operation: It operates from a single 3 V to 5.5 V power supply, making it compatible with a wide range of applications and simplifying power management.
• 3 V Logic Compatible: Inputs are 3 V logic compatible when operating from a 5 V supply, ensuring compatibility with modern microcontrollers and digital logic.
• Enhanced ESD Protection: The device is equipped with robust electrostatic discharge (ESD) protection, enhancing its durability and lifespan.
• Extended Temperature Range: It is operational over the extended industrial temperature range of -40°C to +125°C, making it suitable for harsh environments.

Applications

The ADG5409BRUZ-REEL7 is ideal for various applications, including:

• Data acquisition systems
• Communication systems
• Relay replacement
• Audio and video routing
• Industrial process controls

Quality and Packaging

Supplied in a TSSOP (Thin Shrink Small Outline Package) form factor, the ADG5409BRUZ-REEL7 is available in a tape and reel format (REEL7), facilitating automated manufacturing processes. The device adheres to Analog Devices Inc.'s stringent quality standards, ensuring high performance and reliability for critical applications.

Ordering Information

For ordering, the ADG5409BRUZ-REEL7 is available under the Analog Devices Inc. catalog. Customers can request samples or place bulk orders to meet their specific design and production requirements.
