The ADG658YRUZ is a versatile and high-performance analog multiplexer from Analog Devices Inc., a leading company in the design and manufacture of precision high-performance integrated circuits. This product is a part of the robust ADG series, known for its reliability and efficiency in various complex electronic applications.

Key Features

• Multiple Channels: The device features a dual 4-channel multiplexer configuration, allowing for flexible signal routing and increased design options.
• Low On Resistance: With a typical on resistance of just 4.5 ohms, the ADG658YRUZ ensures minimal signal distortion and power loss, making it ideal for precision applications.
• Single Supply Operation: This multiplexer operates from a single 5 V power supply, simplifying power management in system designs.
• Low Power Consumption: The device boasts low power consumption, making it suitable for battery-powered devices and energy-efficient systems.
• TTL/CMOS Compatible: It is compatible with TTL and CMOS logic levels, ensuring easy integration with a wide range of digital systems.

Applications

The ADG658YRUZ is designed for use in various applications that require high-speed, low-power operation and reliable performance. Common applications include:

• Data acquisition systems
• Communication systems
• Audio and video switching
• Automatic test equipment
• Medical instrumentation

Package and Quality

The ADG658YRUZ comes in a compact TSSOP (Thin Shrink Small Outline Package) form factor, making it suitable for space-constrained applications. Additionally, it meets the stringent quality standards of Analog Devices Inc., ensuring high reliability and performance consistency across various environmental conditions.

Technical Specifications

Parameter Value Number of Channels 8 (Dual 4-Channel) On Resistance (Typical) 4.5 ohms Supply Voltage (V<sub>DD) 5 V Operating Temperature Range -40°C to +85°C Package Type TSSOP

For more detailed information, please refer to the ADG658YRUZ datasheet provided by Analog Devices Inc.
