Analog Devices Inc. ADG701BRJZ-REEL7

The ADG701BRJZ-REEL7 is a high-performance, CMOS single-pole, single-throw (SPST) switch from Analog Devices Inc., a leader in high-performance semiconductors. This compact and efficient switch is designed for precision applications that require low on-resistance, low power consumption, and fast switching times.

This particular model comes in a small SOT-23 package, making it ideal for space-constrained applications. It operates over a wide supply voltage range of ±2.7 V to ±5.5 V, providing designers with flexibility in various power environments. The switch conducts equally well in both directions when on and has an input signal range that extends to the supplies.

The ADG701BRJZ-REEL7 features a low on-resistance of typically 0.8 ohms, ensuring minimal signal distortion and power loss. This low on-resistance is matched between channels to within 0.1 ohms and is flat over the full analog signal range, which enhances performance in multiplexing applications and reduces error in precision analog signal processing.

With its low power consumption, the ADG701BRJZ-REEL7 is particularly suitable for portable and battery-powered instruments where power efficiency is crucial. The device also offers a fast switching time of t_ON = 20 ns and t_OFF = 10 ns, allowing for rapid signal routing and increased system responsiveness.

The switch is controlled by a TTL and CMOS compatible digital input, providing easy interfacing with digital logic. It also includes a feature to eliminate the chance of momentary shorting when switching channels, which is important for protecting sensitive downstream components.

Furthermore, the ADG701BRJZ-REEL7 is available in a tape and reel format, denoted by the "REEL7" suffix, which is suitable for automated assembly processes, making it a convenient choice for mass production environments.

With its robust performance and versatile features, the ADG701BRJZ-REEL7 from Analog Devices Inc. is an excellent choice for a wide range of applications, including sample-and-hold systems, test equipment, audio and video switching, and various other analog and digital signal switching applications.
