The ADG779BKSZ-REEL from Analog Devices Inc. is a high-performance, low-voltage, CMOS analog switch designed with a focus on precision and reliability. Packaged in a compact 6-lead SC-70 package, this device is ideal for applications where space is at a premium and performance cannot be compromised.

Key Features:

• Low On-Resistance: The switch offers a low on-resistance of typically 0.5 ohms, ensuring minimal signal distortion and power loss.
• Single Supply Operation: Operating from a single 1.8V to 5.5V supply, it is perfectly suited for portable and battery-powered devices.
• Fast Switching: The device provides fast switching times (t_ON and t_OFF) of 0.25 µs and 0.15 µs respectively, making it appropriate for high-speed applications.
• High Current Handling: With a continuous current rating of up to 300 mA, the ADG779BKSZ-REEL can handle significant current without performance degradation.
• Break-Before-Make Switching: This feature ensures that the switch-off process is completed before the switch-on process begins, preventing any potential short-circuiting between the channels.
• Low Power Consumption: Designed for power-sensitive applications, it features a low power consumption that extends battery life in portable devices.
• ESD Protection: The device includes enhanced electrostatic discharge (ESD) protection, safeguarding the device from unexpected voltage spikes.

Applications:

The ADG779BKSZ-REEL is versatile and can be used in a wide range of applications, including:

• Audio and Video Signal Routing
• Communications Systems
• Data Acquisition Systems
• Portable Devices
• Test Equipment and Instrumentation

Quality and Reliability:

Analog Devices Inc. is known for its commitment to quality, and the ADG779BKSZ-REEL is no exception. It is manufactured to the highest industry standards, ensuring reliable performance in even the most demanding environments.

Whether you are designing a sophisticated communication system or a simple audio interface, the ADG779BKSZ-REEL from Analog Devices Inc. offers the performance and reliability your application demands.
