ADG849YKSZ-REEL by Analog Devices Inc.

The ADG849YKSZ-REEL is a high-performance, CMOS analog switch from Analog Devices Inc., renowned for its precision and reliability in the semiconductor industry. This switch is part of a series known for its low on-resistance and low voltage operation, making it an excellent choice for a wide range of applications, including data acquisition systems, communication systems, and portable devices.

With a single-pole, double-throw (SPDT) configuration, the ADG849YKSZ-REEL offers versatile switching options for your circuit design. The device operates from a single 1.8V to 5.5V supply, ensuring compatibility with various logic levels and providing design flexibility. Moreover, the switch's low on-resistance of typically 0.4 ohms at 5V ensures minimal signal distortion and power loss, making it ideal for high-frequency signal switching.

The ADG849YKSZ-REEL is available in a compact SC70 package, which is highly beneficial for space-constrained applications. The device's small footprint does not compromise its performance, as it still delivers high-speed switching with a t<sub>ON of 0.25µs and a t<sub>OFF of 0.2µs, ensuring that signals are routed quickly and efficiently.

One of the key features of this analog switch is its enhanced electrostatic discharge (ESD) protection. The ADG849YKSZ-REEL can withstand ESD events up to 2 kV, according to the Human Body Model, providing robustness and reliability in environments where ESD events are a concern.

For designers concerned about power consumption, the ADG849YKSZ-REEL offers a low power dissipation, with a typical ICQ of only 1nA, which is ideal for battery-powered and portable applications where power efficiency is crucial.

As a part of the REEL package, this product is provided in tape and reel packaging, facilitating efficient handling and placement in automated manufacturing processes. This packaging ensures that the ADG849YKSZ-REEL is well-suited for high-volume production environments.

In summary, the ADG849YKSZ-REEL from Analog Devices Inc. is a versatile, high-performance analog switch that combines low on-resistance, low voltage operation, fast switching speeds, and enhanced ESD protection, all in a small package suitable for a variety of applications.
