The ADM3202ARNZ-REEL7 is a robust, high-speed, two-channel RS-232/V.28 transceiver from the reputable Analog Devices Inc. This component is specifically designed to operate from a single 3.3V power supply, making it an ideal choice for portable or space-constrained applications requiring efficient power management.

Key Features

• Interface Type: RS-232
• Number of Drivers/Receivers: 2/2
• Data Rate: Up to 460 kbps
• Operating Voltage: 3.0V to 3.6V
• ESD Protection: ±15kV on Human Body Model (HBM)
• Low Power Shutdown: Yes
• Package: 16-SOIC (0.154", 3.90mm Width)
• Supply Current: 1mA (typical)
• Temperature Range: -40°C to +85°C

Product Highlights

The ADM3202ARNZ-REEL7 transceiver incorporates Analog Devices Inc.'s advanced, proprietary ESD protection circuitry, safeguarding the device against electrostatic discharges as high as ±15kV. The integrated charge pump circuitry generates the necessary RS-232 voltage levels from a single 3.3V supply, reducing the need for additional power supplies within the system.

With its low-power shutdown mode, the ADM3202ARNZ-REEL7 conserves power when not in use, making it highly efficient for battery-powered devices. The device is capable of achieving data rates up to 460 kbps, allowing for high-speed data communication that is essential for modern digital communication systems.

The transceiver is packaged in a compact 16-SOIC form factor, which is conducive to streamlined PCB layouts and space-saving designs. Its industrial temperature range of -40°C to +85°C ensures reliable operation under extreme environmental conditions, making it suitable for a wide array of industrial applications.

Applications

Common applications for the ADM3202ARNZ-REEL7 include portable computing devices, PDAs, digital cameras, and any other RS-232 data interface communication systems. Its reliability and versatility make it an excellent choice for designers looking to implement robust serial communication interfaces with minimal power consumption and maximum protection.
