ADP222ACPZ-1833-R7 Real Image ADP222ACPZ-1833-R7 label picture ADP222ACPZ-1833-R7 real image
Same model may have multiple batches, images only for reference.
ADP222ACPZ-1833-R7 Real Image ADP222ACPZ-1833-R7 label picture ADP222ACPZ-1833-R7 real image
ADP222ACPZ-1833-R7 Real Image ADP222ACPZ-1833-R7 label picture ADP222ACPZ-1833-R7 real image
Same model may have multiple batches, images only for reference.

ADP222ACPZ-1833-R7

Part No ADP222ACPZ-1833-R7
Manufacturer Analog Devices Inc.
Catalog PMIC - Voltage Regulators - Linear
Description IC REG LINEAR 1.8V/3.3V 8LFCSP / Dual, 300 mA Output, Low Noise
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Manufacturer Analog Devices Inc.
Packaging Reel
Output Configuration Positive
Output Type Fixed
Number of Regulators 2
Maximum Input Voltage 5.5V
Voltage - Output (Min/Fixed) 1.8V, 3.3V
Maximum Dropout Voltage -, 0.26V at 300mA
Current - Output 300mA, 300mA
Current - Quiescent (Iq) 150μA
Current - Supply (Maximum) 450μA
Control Features Enable
Protection Features Over Current, Over Temperature
Temperature Range - Operating -40°C ~ 125°C
Mounting Style SMD
Manufacturer Package 8-UFDFN Exposed Pad, CSP
Supplier Device Package 8-LFCSP-UD (2x2)
Part Number Series ADP222
Manufacturer Pack Quantity 3,000
MSL Level 1 (Unlimited)
Popularity Low
Supply and Demand Status Limited
Win Source Part Number 811828-ADP222ACPZ-1833-R7
Ultra Librarian 3D Model Ultra Librarian ADP222ACPZ-1833-R7 CAD Model

Description

The ADP222ACPZ-1833-R7 from Analog Devices Inc. is a positive fixed output voltage regulator with enable control feature.

  • Maximum Input Voltage: 5.5V
  • Current Output: 300mA (for both regulators)
  • Voltage Output: 1.8V and 3.3V
  • Package: 8-LFCSP-UD (2x2)
  • Maximum Dropout Voltage: 0.26V @ 300mA
  • Protection: Over Current, Over Temperature
