Product Overview: ADP7118AUJZ-R7 by Analog Devices Inc.

The ADP7118AUJZ-R7 is a high-performance, CMOS linear regulator offered by Analog Devices Inc., a leader in the semiconductor industry. This device provides a stable and accurate voltage supply, making it an ideal choice for precision applications that require low noise, high PSRR (Power Supply Rejection Ratio), and low dropout voltage.

Designed to operate with an input voltage range from 2.7V to 20V, the ADP7118 is capable of delivering up to 200 mA of output current. This makes it suitable for a wide variety of applications, including but not limited to, portable and battery-powered devices, medical instruments, and sensitive analog and RF circuits.

Key Features:

• Output Voltage Range: The ADP7118AUJZ-R7 can be configured to deliver a fixed output voltage from 1.2V to 5.0V, or an adjustable output voltage from 1.2V to VIN – VDO, ensuring flexibility for different design requirements.
• High PSRR: With a PSRR of 70 dB at 10 kHz, this regulator significantly attenuates input voltage noise, providing a cleaner supply voltage to sensitive components.
• Low Dropout Voltage: The low dropout performance enables efficient regulation even when the input-to-output voltage differential is minimal, making it ideal for battery-operated devices where power efficiency is critical.
• Low Noise: The ADP7118AUJZ-R7 boasts an ultra-low output noise of typically 9 µVRMS, making it an excellent choice for noise-sensitive applications such as precision instrumentation and high-end audio equipment.
• Thermal Overload and Short-Circuit Protection: The device incorporates safety features that protect it against adverse conditions, ensuring reliability and longevity.
• Compact Package: The regulator is available in a small 5-lead TSOT package, which is highly suitable for space-constrained applications.

Applications:

The versatile nature of the ADP7118AUJZ-R7 allows it to be used in a diverse range of applications, including:

• Portable and battery-powered electronics
• Data acquisition systems
• Medical devices
• RF applications
• High-end audio equipment
• Analog and digital sensors

Analog Devices Inc. has a reputation for creating high-quality, reliable components, and the ADP7118AUJZ-R7 is no exception. It represents a balance of performance, flexibility, and efficiency, making it a valuable addition to any power management solution.
