Analog Devices Inc. ADUC7060BSTZ32 Microcontroller

The ADUC7060BSTZ32 is a precision analog microcontroller designed by Analog Devices Inc. to offer a seamless integration of analog peripherals with digital processing power. This microcontroller is a perfect solution for a wide range of applications, including industrial control systems, sensor signal conditioning, instrumentation, and smart sensing systems.

At the heart of the ADUC7060BSTZ32 is a 32-bit ARM7TDMI MCU core that provides high-performance data processing capabilities. This core is supported by 128 KB of non-volatile Flash/EE memory and 8 KB of SRAM, offering ample space for complex application code and data storage.

The device boasts a rich set of analog features, including dual 24-bit sigma-delta ADCs with a maximum channel count of 12. These ADCs provide high-resolution conversion, making the ADUC7060BSTZ32 an ideal choice for precision measurement applications. The ADCs are complemented by a 4-channel, 12-bit DAC, and a range of other analog peripherals such as a temperature sensor and a PGA (Programmable Gain Amplifier), enhancing its flexibility in various sensing and control tasks.

Connectivity options include UART, SPI, and I²C interfaces, allowing the ADUC7060BSTZ32 to communicate with other digital devices and sensors easily. Additionally, it comes with an on-chip, kernel-independent debug agent, which simplifies the development and debugging process, reducing time-to-market.

The microcontroller operates within an extended industrial temperature range and is available in a 32-lead LFCSP package. This compact form factor, combined with its low power consumption, makes it suitable for space-constrained and power-sensitive applications.

With its integration of precision analog and digital functionalities, the ADUC7060BSTZ32 from Analog Devices Inc. stands out as a robust and versatile microcontroller that can meet the demands of sophisticated and precise control applications.

Product highlights:

• 32-bit ARM7TDMI core for efficient processing
• Dual 24-bit sigma-delta ADCs for high-resolution measurements
• 128 KB Flash/EE and 8 KB SRAM for robust application storage
• Comprehensive set of analog peripherals for versatile use
• Multiple communication interfaces: UART, SPI, and I²C
• Extended industrial temperature range
• Compact 32-lead LFCSP package
