ADUM5402ARWZ Digital Isolator by Analog Devices Inc.

The ADUM5402ARWZ is a robust, high-performance digital isolator manufactured by Analog Devices Inc., a leader in the field of high-performance analog, mixed-signal, and digital signal processing integrated circuits. This product is designed to enhance system reliability and protect users and sensitive circuitry from high-voltage environments through electrical isolation.

Key Features

• Quad-Channel Isolation: The ADUM5402ARWZ features four independent isolation channels, providing flexibility in isolating data lines in various configurations.
• iCoupler® Technology: Utilizing Analog Devices' proprietary iCoupler technology, this digital isolator offers superior performance while maintaining low power consumption and high data integrity.
• Integrated, Isolated DC-to-DC Converter: This component includes an integrated, isolated DC-to-DC converter, which simplifies power supply design by providing isolated power for the isolated side.
• High Data Rates: Capable of supporting data rates up to 10 Mbps, the ADUM5402ARWZ is suitable for high-speed data transfer applications.
• High-Temperature Operation: With an operational temperature range from -40°C to +125°C, it is ideal for use in harsh industrial environments.

Applications

Thanks to its robust design and reliable performance, the ADUM5402ARWZ is well-suited for a wide range of applications, including:

• Industrial automation and control systems
• Medical equipment with stringent safety requirements
• Isolated sensor interfaces and data acquisition systems
• Isolated SPI, I2C, or UART interfaces

Product Specifications

The ADUM5402ARWZ comes in a 16-lead SOIC wide body package, ensuring compatibility with standard PCB layouts. It offers a high isolation voltage of 2500 Vrms, providing a robust barrier against voltage spikes and surges. Additionally, it is compliant with safety regulations, including UL, CSA, and VDE certifications, ensuring it meets global safety standards.

For engineers and designers seeking a reliable solution for their electrical isolation needs, the ADUM5402ARWZ from Analog Devices Inc. offers an excellent blend of performance, integration, and safety.
