The LT3090IMSE#TRPBF is a high-performance, adjustable linear regulator from Analog Devices Inc., designed to deliver superior regulation and low noise in a variety of applications. This regulator features a wide input voltage range and is capable of supplying up to 500mA of output current with a dropout voltage of only 350mV at full load, making it an excellent choice for battery-powered devices and precision instrumentation.

Key Features

• Output Current: Capable of delivering up to 500mA of continuous output current.
• Wide Input Voltage Range: Operates with an input voltage from 1.8V to 20V, providing flexibility in various power supply configurations.
• Adjustable Output Voltage: The output voltage can be set from 0.8V to 10V with an external resistor divider, allowing for custom voltage settings tailored to specific needs.
• Low Dropout Voltage: The low dropout voltage of only 350mV at full load ensures efficient operation even with low input-to-output voltage differentials.
• Stable with Low ESR Capacitors: The LT3090IMSE#TRPBF is stable with ceramic, tantalum, or aluminum electrolytic capacitors, providing flexibility in choice of output capacitors.
• Thermal Protection: Integrated thermal shutdown protection safeguards the device against overheating, enhancing reliability.
• Current Monitoring: Features an output current monitor that can be used to drive LEDs or provide a feedback signal for power management systems.

Applications

• Portable and Battery-Powered Equipment
• Precision Instrumentation
• Automotive Electronics
• Industrial Control Systems
• Low Noise Power Supplies

The LT3090IMSE#TRPBF is offered in a small MSOP-12 package, making it an ideal solution for space-constrained applications. With its precise voltage regulation, robust protection features, and wide input voltage range, this linear regulator from Analog Devices Inc. ensures high performance and reliability for a diverse range of electronic systems.
