Product Overview

The LTM4601HVIY#PBF is a high-efficiency, switch-mode step-down power module designed and manufactured by Analog Devices Inc. This advanced power solution integrates a DC/DC controller, power switches, inductor, and support components into a compact, encapsulated package. The module is designed to simplify the implementation of power conversion in complex systems, offering ease of use combined with high performance, which is ideal for telecommunications, industrial, and automotive applications.

Key Features

• High Efficiency: The LTM4601HVIY#PBF utilizes a synchronous buck regulator topology to provide high efficiency and reduce power loss during conversion.
• Wide Input Voltage Range: This power module operates over a wide input voltage range from 4.5V to 20V, accommodating a variety of power sources and system voltages.
• Adjustable Output Voltage: The output voltage can be adjusted from 0.6V to 5V, making the module highly versatile for different low-voltage applications.
• High Output Current: It delivers up to 10A of continuous output current, catering to high-power applications.
• Integrated Components: The inclusion of an inductor and all necessary circuitry within the package simplifies the design process and reduces external component count.
• Thermal Management: The LTM4601HVIY#PBF features over-temperature protection and operates within a temperature range of -40°C to +125°C, ensuring reliable performance in harsh environments.
• Compact Package: The module's small footprint and low profile (15mm x 15mm x 2.8mm LGA package) make it ideal for space-constrained applications.

Applications

The versatility and robustness of the LTM4601HVIY#PBF make it suitable for a wide range of applications, including:

• Telecommunications infrastructure
• Industrial equipment
• Automotive electronics
• Datacom and storage systems
• Medical devices
• Point-of-load applications

Analog Devices Inc. is known for its commitment to quality and reliability, and the LTM4601HVIY#PBF is no exception. It represents a complete power management solution that accelerates time-to-market for designers while maintaining high performance and reliability.
