Product Overview: LTM8056IY#PBF from Analog Devices Inc.

The LTM8056IY#PBF is a highly versatile and efficient micro-module regulator from Analog Devices Inc., designed to cater to a broad range of power supply requirements. This compact and robust power management solution is part of Analog Devices' µModule (micro-module) series, which integrates the DC/DC controller, power switches, inductor, and support components all within a single package. This integration simplifies the design process and accelerates the product development cycle, making it a go-to choice for engineers.

With its wide input voltage range, the LTM8056IY#PBF is capable of operating from a variety of power sources, ranging from 6V to 58V. This feature ensures compatibility with a diverse array of applications, from automotive and industrial systems to telecommunications and portable devices. The output voltage is adjustable from 1.2V to 24V, providing the flexibility needed to power different types of loads.

The LTM8056IY#PBF employs advanced switching regulator technology to deliver high efficiency, which is crucial for thermal management and energy-saving purposes. It is capable of delivering up to 2.5A of continuous output current, or 3.5A peak, making it suitable for applications that demand a high power density. Furthermore, the device supports frequency synchronization and has selectable operating modes, including Burst Mode operation for low noise performance and improved light-load efficiency.

The micro-module's robust design includes built-in protection features such as overvoltage, overcurrent, and over-temperature protection, ensuring reliable operation under various conditions. The LTM8056IY#PBF is packaged in a compact over-molded land grid array (LGA) package measuring just 15mm x 15mm x 5.01mm, which allows for efficient use of board space.

Engineers looking for a power solution that combines convenience, performance, and reliability will find the LTM8056IY#PBF to be an excellent choice. Its ease of use, coupled with the strong support and documentation from Analog Devices Inc., makes this micro-module regulator a valuable component in any power supply design.
