The LTM9004IV-AA#PBF is a complete system in a package (SiP) from Analog Devices Inc. that features a high-performance 14-bit, 125Msps analog-to-digital converter (ADC) integrated with a fixed gain differential amplifier and an anti-aliasing filter. This product is designed to provide a compact, easy-to-use solution for complex digital signal processing applications such as medical imaging, communications, and industrial instrumentation.

Key Features

• Integrated ADC: The 14-bit, 125Msps ADC offers precise digital conversion, ensuring high fidelity in signal processing tasks.
• Fixed Gain Amplifier: The differential amplifier with a fixed gain improves signal-to-noise ratio and enhances signal integrity.
• Anti-Aliasing Filter: The built-in anti-aliasing filter effectively reduces signal distortion and prevents the folding of high-frequency noise into the signal band.
• High Integration: The combination of ADC, amplifier, and filter in a single package simplifies design and reduces the footprint on the PCB, leading to a more compact and reliable end product.
• Thermal Performance: Enclosed in a 15mm x 15mm LGA package, the LTM9004IV-AA#PBF is engineered for excellent thermal performance, ensuring stability and longevity in various operating conditions.

Applications

• Medical Imaging Systems
• Wireless and Wired Communications
• Test and Measurement Equipment
• Industrial Control Systems

Quality and Reliability

Analog Devices Inc. is renowned for its commitment to quality and reliability, and the LTM9004IV-AA#PBF is no exception. This product is built to meet the stringent requirements of industrial-grade applications, ensuring consistent performance and durability.

Ordering Information

The LTM9004IV-AA#PBF is available for order now. For detailed specifications, application support, and ordering information, please visit Analog Devices Inc.'s official website or contact their sales and support team.
