Product Overview: MAXM17502ALI#T from Analog Devices Inc.

The MAXM17502ALI#T, from the renowned manufacturer Analog Devices Inc., is a highly integrated, fixed-frequency, step-down power module in a compact package. This product is designed to simplify power supply design by reducing the need for multiple external components, thereby saving on board space and reducing time to market for a wide range of applications.

Key Features

• High-Efficiency Power Solution: The module integrates a synchronous wide input range step-down regulator with built-in inductors and capacitors, delivering high efficiency and reducing power loss.
• Compact Design: Housed in a small 6.5mm x 6.75mm x 2.9mm, 29-pin LGA-EP (Exposed Pad) package, this product is ideal for space-constrained applications.
• Wide Input Voltage Range: It operates over a wide input voltage range from 4.5V to 42V, making it suitable for various industrial, automotive, and communication systems.
• Adjustable Output Voltage: The output voltage is adjustable from 0.9V to 12V, providing flexibility to power a broad range of devices.
• Thermal Management: The module features an efficient thermal design with an exposed pad for enhanced thermal dissipation.
• Protection Features: It includes overcurrent protection, overtemperature protection, and undervoltage lockout to ensure the safety and reliability of your power supply.

Applications

The MAXM17502ALI#T is an ideal power solution for a variety of applications, including:

• Industrial Control Systems
• Automotive Infotainment and Body Electronics
• Telecommunications Equipment
• Networking Devices
• Point-of-Load Power Supplies

Reliability and Quality

Analog Devices Inc. is known for its commitment to quality and reliability, and the MAXM17502ALI#T is no exception. It is designed to meet the stringent requirements of industrial and automotive applications, ensuring long-term performance even under harsh conditions.

With its combination of integration, efficiency, compactness, and robust protection features, the MAXM17502ALI#T from Analog Devices Inc. stands out as a powerful, reliable, and convenient choice for designers looking to optimize their power supply solutions.
