Analog Devices Inc. OP482GSZ High-Speed Operational Amplifier

The OP482GSZ from Analog Devices Inc. is a high-performance, quad operational amplifier that combines a high speed of response with rail-to-rail output swings. This operational amplifier is designed to meet the stringent requirements of fast signal processing applications while maintaining a low power consumption profile, making it ideal for battery-powered and portable devices.

Key Features and Benefits:

• High Speed: With a slew rate typically at 5 V/µs, the OP482GSZ ensures fast and efficient signal processing, making it suitable for applications requiring swift response times.
• Wide Bandwidth: The device offers a gain bandwidth product of 4 MHz, allowing it to handle a wide range of frequencies and making it versatile for various applications.
• Low Power Consumption: Despite its high-speed capabilities, the OP482GSZ maintains low power consumption, which is critical for extending the battery life in portable devices.
• Rail-to-Rail Output: The rail-to-rail output capability provides increased dynamic range, which is especially useful in single-supply operations and maximizes the signal amplitude without clipping.
• Quad Configuration: The four amplifiers in one package offer compact and efficient design possibilities, reducing the number of components and board space required.
• Stable with Capacitive Loads: The OP482GSZ is designed to be stable with capacitive loads, enhancing its reliability and performance in feedback and buffering applications.
• Wide Supply Voltage Range: It operates with a supply voltage range from 3 V to 36 V, or ±1.5 V to ±18 V in dual-supply configurations, providing flexibility in various circuit designs.
• SOIC Package: The device is housed in a small outline integrated circuit (SOIC) package, which is suitable for surface mount technology (SMT) and helps in reducing the overall size of the circuit.

The OP482GSZ operational amplifier is an excellent choice for designers looking for a blend of speed, power efficiency, and performance. It is commonly used in applications such as active filters, fast amplifiers, integrators or differentiators, and many other circuits requiring high-speed signal conditioning.

With its robust feature set and high level of integration, the OP482GSZ from Analog Devices Inc. represents a reliable and versatile solution for a broad range of electronic designs.
