Introducing the SSM2380CBZ-REEL from Analog Devices Inc.

The SSM2380CBZ-REEL is a state-of-the-art audio amplifier that offers a perfect blend of efficiency and performance for a wide range of audio applications. Manufactured by Analog Devices Inc., a leader in high-performance semiconductors, this audio amplifier is designed to deliver exceptional sound quality with minimal power consumption.

Key Features

• Class-D Amplifier: The SSM2380CBZ-REEL operates as a Class-D amplifier, ensuring high efficiency and reduced heat generation. This makes it ideal for portable applications where battery life and thermal management are critical.
• Output Power: Capable of delivering 2 x 1.5W into 8 Ω loads or 2 x 2W into 4 Ω loads, this amplifier can power a range of speakers with clarity and strength.
• Supply Voltage: It operates over a wide supply voltage range from 2.5 V to 5.5 V, providing design flexibility for various power supply scenarios.
• High-Efficiency: With its high-efficiency output, the SSM2380CBZ-REEL minimizes power loss and extends battery life in portable devices.
• Pop & Click Suppression: The device includes a pop & click suppression circuit that reduces noise during turn-on and turn-off events, ensuring a smooth audio experience.
• Thermal Overload Protection: Built-in thermal overload protection safeguards the device from damage due to excessive heat.

Applications

The SSM2380CBZ-REEL is versatile and can be used in various audio applications, including:

• Mobile Phones
• Tablet Devices
• Portable Media Players
• Personal Computers
• Portable Gaming Systems

Package and Availability

Presented in a compact 9-ball, 1.5 mm x 1.5 mm WLCSP (Wafer Level Chip Scale Package), the SSM2380CBZ-REEL is designed for space-constrained applications. Its reel packaging facilitates efficient integration into automated manufacturing processes, making it a convenient choice for high-volume production.

With its impressive combination of power, efficiency, and size, the SSM2380CBZ-REEL from Analog Devices Inc. is an excellent choice for designers looking to enhance the audio performance of their next-generation consumer electronics.
