Same model may have multiple batches, images only for reference.

BWD4815

Name: BWD4815
Brand: Bel Power Solutions
SKU: 573823
Availability: InStock
Rating: 4.91 (5 reviews)

Get a Quote

Part No	BWD4815
Manufacturer	Bel Power Solutions
Catalog	Power Supplies Board Mount DCDC Converters
Description	DC DC CONVERTER +/-15V 3W
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Power Supplies - Board Mount - DC DC Converters
Mfr	Bel Power Solutions
Series	BWD (3W)
Package	Bulk
Product Status	Obsolete
Type	Isolated Module
Number of Outputs	2
Voltage - Input (Min)	36V
Voltage - Input (Max)	72V
Voltage - Output 1	15V
Voltage - Output 2	-15V
Current - Output (Max)	100mA, 100mA
Power (Watts)	3 W
Voltage - Isolation	500 V
Applications	ITE (Commercial)
Features	SCP
Temperature Range - Operating	-25°C ~ 85°C
Efficiency	79%
Mounting Type	Through Hole
Package / Case	24-DIP Module, 10 Leads
Size / Dimension	1.25" L x 0.80" W x 0.52" H (31.8mm x 20.3mm x 13.2mm)
Standard Package	2 pcs
MSL Level	1 (Unlimited)
REACH Status	REACH Unaffected
ECCN	EAR99
HTSUS	8504.40.9580
Win Source Part Number	573823-BWD4815
Ultra Librarian 3D Model	Ultra Librarian BWD4815 CAD Model

Alternative Products

Description

The BWD4815 is a 3W isolated module from Bel Power Solutions.

Series: BWD
Size: 1.25" L x 0.80" W x 0.52" H
Protection: Short Circuit Protection (SCP)
Outputs: Two
Maximum Current: 100mA each
Voltages: 15V and -15V
Input Voltage Range: 36V to 72V
Efficiency: 79%
Applications: ITE (Commercial)
Mounting Type: Through-Hole
Package: 24-DIP
Leads: 10
Operating Temperature Range: -25°C to 85°C
Voltage Isolation: 500V
ECCN: EAR99
Status: Obsolete
Standard Package: 2 pcs
