DFA20E12S5 Power-One
Same model may have multiple batches, images only for reference.

DFA20E12S5

Part No DFA20E12S5
Manufacturer Bel Power Solutions
Catalog Power Supplies Board Mount DCDC Converters
Description DC DC CONVERTER 5V 20W
Datasheet
DFA20E12S5 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Power Supplies - Board Mount - DC DC Converters
Mfr Bel Power Solutions
Series DFA20
Package Bulk
Product Status Obsolete
Type Isolated Module
Number of Outputs 1
Voltage - Input (Min) 9V
Voltage - Input (Max) 18V
Voltage - Output 1 5V
Current - Output (Max) 4A
Power (Watts) 20 W
Voltage - Isolation 700 V
Applications ITE (Commercial)
Temperature Range - Operating -50°C ~ 100°C
Efficiency 79%
Mounting Type Through Hole
Package / Case 7-DIP Module
Size / Dimension 2.02" L x 2.02" W x 0.45" H (51.3mm x 51.3mm x 11.4mm)
Standard Package 20 pcs
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8504.40.9580
Win Source Part Number 584518-DFA20E12S5
Ultra Librarian 3D Model Ultra Librarian DFA20E12S5 CAD Model

Description

The DFA20E12S5 is a DC-DC converter module from Bel Power Solutions.

  • Series: DFA20
  • Application: Isolated Module
  • Power Rating: 20 watts
  • Voltage Isolation: 700 volts
  • Output(s): Single
  • Maximum Output Current: 4A
  • Voltage Output: 5V
  • Efficiency: 79%
  • Temperature Range: -50°C to 100°C
  • Package: Bulk
  • Standard Package: 20 pieces
  • Status: Obsolete
  • Application: Commercial ITE
