Same model may have multiple batches, images only for reference.
3266P-1-501LF Real Image
Same model may have multiple batches, images only for reference.

3266P-1-501LF

Part No 3266P-1-501LF
Manufacturer Bourns Inc.
Catalog Trimmer Potentiometers
Description TRIMMER 500 OHM .25W PC PIN
Datasheet
3266P-1-501LF Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Potentiometers, Variable Resistors
Manufacturer Bourns Inc.
Series Trimpot 3266 - Sealed
Packaging Tube
Resistance (Ohms) 500
Power (Watts) 0.25W, 1/4W
Tolerance ±10%
Temperature Coefficient ±100ppm/°C
Number of Turns 12
Adjustment Type Side Adjustment
Resistive Material Cermet
Mounting Style Through Hole
Termination Style PC Pins
Dimension Rectangular - 0.250" x 0.174" Face x 0.174" H (6.35mm x 4.42mm x 4.42mm)
Win Source Part Number 763190-3266P-1-501LF
Family Name 3266
Introduction Date May 18, 2004
ECCN EAR99
Country of Origin Costa Rica
Halogen Free Compliant
Estimated EOL Date 2025
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian 3266P-1-501LF CAD Model

Description

The Bourns Inc. Trimpot 3266 - Sealed is a high-quality potentiometer that is designed for use in a variety of electronic applications.

  • Power Rating: 0.25W, 1/4W
  • Resistance: 500 ohms
  • Turns: 12
  • Adjustment: Side adjustment
  • Material: Cermet resistive material
  • Shape: Rectangular 0.250" x 0.174" face x 0.174" H (6.35mm x 4.42mm x 4.42mm)
  • Pins: PC pins
  • Mounting: Through-hole
  • Tolerance: ±10%
  • Temperature Coefficient: ±100ppm/°C
  • Packaging: Tube
  • Series: 3266 family
