SDE0403A-4R7M Real Image
Same model may have multiple batches, images only for reference.

SDE0403A-4R7M

Part No SDE0403A-4R7M
Manufacturer Bourns Inc.
Catalog Fixed Inductors
Datasheet
SDE0403A-4R7M Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Inductors, Coils, Chokes>Fixed Inductors
Mfr Bourns Inc.
Series SDE0403A
Package Tape & Reel
Type Drum Core, Wirewound
Material - Core Ferrite
Inductance 4.7 µH
Tolerance ±20%
Current Rating (Amps) 1.65 A
Current - Saturation (Isat) 2.2A
Shielding Unshielded
DC Resistance (DCR) 108mOhm Max
Frequency - Self Resonant 50MHz
Ratings AEC-Q200
Temperature Range - Operating -40°C ~ 125°C
Inductance Frequency - Test 1 MHz
Mounting SMD (SMT)
Package / Case Nonstandard
Dimension 0.177" L x 0.157" W (4.50mm x 4.00mm)
Height - Seated (Max) 0.138" (3.50mm)
Base Product Number SDE0403A
Other Names SDE0403A-4R7MDKR,SDE0403A-4R7MCT,SDE0403A-4R7MTR
Standard Package 2,000
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8504.50.4000
Win Source Part Number 1274931-SDE0403A-4R7M
Ultra Librarian 3D Model Ultra Librarian SDE0403A-4R7M CAD Model

Description

The Bourns Inc. SDE0403A-4R7M is a reliable fixed inductor that is ideal for various applications.

  • Inductance: 4.7 µH
  • Tolerance: ±20%
  • DC Resistance: 108mOhm Max
  • Current Rating: 1.65 A
  • Mounting Technology: SMD (SMT)
  • Temperature Range: -40°C to 125°C
