SRP3012C-R47M Real Image
Same model may have multiple batches, images only for reference.

SRP3012C-R47M

Part No SRP3012C-R47M
Manufacturer Bourns Inc.
Catalog Fixed Inductors
Datasheet
SRP3012C-R47M Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Inductors, Coils, Chokes>Fixed Inductors
Mfr Bourns Inc.
Series SRP3012C
Package Tape & Reel
Material - Core Metal
Inductance 470 nH
Tolerance ±20%
Current Rating (Amps) 5 A
Current - Saturation (Isat) 6.5A
Shielding Shielded
DC Resistance (DCR) 30mOhm Max
Q @ Freq 10 @ 100kHz
Frequency - Self Resonant 98MHz
Temperature Range - Operating -40°C ~ 125°C
Inductance Frequency - Test 100 kHz
Mounting SMD (SMT)
Package / Case Nonstandard
Dimension 0.138" L x 0.126" W (3.50mm x 3.20mm)
Height - Seated (Max) 0.047" (1.20mm)
Other Names 118-SRP3012C-R47MDKR,118-SRP3012C-R47MTR,118-SRP3012C-R47MCT
Standard Package 4,000
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8504.50.8000
Win Source Part Number 1273981-SRP3012C-R47M
Ultra Librarian 3D Model Ultra Librarian SRP3012C-R47M CAD Model

Description

The SRP3012C series inductor from Bourns Inc. is a shielded type inductor that comes in a tape and reel package.

  • Inductance: 470nH
  • Q @ Freq: 10 @ 100kHz
  • Frequency Self-Resonant: 98MHz
  • Height: 0.047" (1.20mm)
  • Tolerance: ±20%
  • Core Material: Metal
  • Temperature Range: -40°C to 125°C
  • DC Resistance (DCR): 30mOhm Max
  • Supplier Device Package: -
  • Current Rating: 5A
  • Inductance Frequency Test: 100 kHz
  • Other Part Numbers: SRP3012C-R47MCT, 118-SRP3012C-R47MDKR, 118-SRP3012C-R47MTR, 3314R-1-503ECT, 3314R-1-503EDKR, 3314R-1-503EDKR-ND, and 3314R-1-503ETR
