Same model may have multiple batches, images only for reference.
SRR4028-560Y Real Image
Same model may have multiple batches, images only for reference.

SRR4028-560Y

Part No SRR4028-560Y
Manufacturer Bourns Inc.
Catalog Fixed Inductors
Datasheet
SRR4028-560Y Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Inductors, Coils, Chokes>Fixed Inductors
Mfr Bourns Inc.
Series SRR4028
Package Tape & Reel
Type Drum Core, Wirewound
Material - Core Ferrite
Inductance 56 µH
Tolerance ±30%
Current Rating (Amps) 700 mA
Current - Saturation (Isat) 410mA
Shielding Shielded
DC Resistance (DCR) 320mOhm Max
Q @ Freq 9 @ 2.52MHz
Frequency - Self Resonant 13MHz
Temperature Range - Operating -40°C ~ 125°C
Inductance Frequency - Test 100 kHz
Mounting SMD (SMT)
Package / Case 1919 (4848 Metric)
Dimension 0.189" L x 0.189" W (4.80mm x 4.80mm)
Height - Seated (Max) 0.118" (3.00mm)
Base Product Number SRR4028
Other Names -SRR4028-560Y,SRR4028-560Y,-SRR4028-560YTR,SRR4028-560YTR,SRR4028-560YDKR,SRR4028-560YCT,-SRR4028-560YCT,-SRR4028-560Y,SRR4028560Y
Standard Package 500
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8504.50.4000
Win Source Part Number 1273315-SRR4028-560Y
Ultra Librarian 3D Model Ultra Librarian SRR4028-560Y CAD Model

Description

Bourns' SRR4028-560Y is a drum core, wirewound inductor that comes in a shielded package.

  • Inductance: 56 µH
  • Tolerance: ±30%
  • DC Resistance: 320mOhm Max
  • Current Rating: 700 mA
  • Q @ Freq: 9 @ 2.52MHz
  • Frequency of Self-Resonant: 13MHz
  • Operating Temperature Range: -40°C to 125°C
  • Material: Ferrite
  • Package: 1919 (4848 Metric)
  • Mounting: SMD (SMT)
  • Rated: EAR99
  • REACH: Unaffected
