SRR6040A-470M Real Image
Same model may have multiple batches, images only for reference.

SRR6040A-470M

Part No SRR6040A-470M
Manufacturer Bourns Inc.
Catalog Fixed Inductors
Datasheet
SRR6040A-470M Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Inductors, Coils, Chokes>Fixed Inductors
Mfr Bourns Inc.
Series SRR6040A
Package Tape & Reel
Material - Core Ferrite
Inductance 47 µH
Tolerance ±20%
Current Rating (Amps) 950 mA
Current - Saturation (Isat) 850mA
Shielding Shielded
DC Resistance (DCR) 160mOhm Max
Ratings AEC-Q200
Temperature Range - Operating -40°C ~ 125°C
Inductance Frequency - Test 10 kHz
Mounting SMD (SMT)
Package / Case Nonstandard, Corner Terminals
Dimension 0.264" L x 0.264" W (6.70mm x 6.70mm)
Height - Seated (Max) 0.157" (4.00mm)
Base Product Number SRR6040A
Other Names SRR6040A-470MDKR,SRR6040A-470MCT,SRR6040A-470MTR
Standard Package 1,000
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8504.50.4000
Win Source Part Number 1273215-SRR6040A-470M
Ultra Librarian 3D Model Ultra Librarian SRR6040A-470M CAD Model

Description

The Bourns Inc. SRR6040A-470M is a shielded fixed inductor with an inductance of 47μH and a maximum DC resistance of 160mΩ.

  • Height: 0.157” (4.00mm)
  • Mounted: SMD (SMT)
  • Package/Case: Nonstandard, corner terminal
  • Series: SRR6040A
  • Rated: AEC-Q200
  • Temperature Range: -40°C to 125°C
  • Supplied: Tape and reel package of 1000 units
  • REACH: Not affected
