SRU1028-330Y Real Image
Same model may have multiple batches, images only for reference.

SRU1028-330Y

Part No SRU1028-330Y
Manufacturer Bourns Inc.
Catalog Fixed Inductors
Datasheet
SRU1028-330Y Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Inductors, Coils, Chokes>Fixed Inductors
Mfr Bourns Inc.
Series SRU1028
Package Tape & Reel
Type Drum Core, Wirewound
Material - Core Ferrite
Inductance 33 µH
Tolerance ±30%
Current Rating (Amps) 1.25 A
Current - Saturation (Isat) 1.2A
Shielding Shielded
DC Resistance (DCR) 139mOhm
Q @ Freq 24 @ 2.52MHz
Frequency - Self Resonant 12MHz
Temperature Range - Operating -40°C ~ 125°C
Inductance Frequency - Test 100 kHz
Mounting SMD (SMT)
Package / Case Nonstandard
Dimension 0.394" L x 0.394" W (10.00mm x 10.00mm)
Height - Seated (Max) 0.122" (3.10mm)
Base Product Number SRU1028
Other Names SRU1028-330YCT,SRU1028-330Y,SRU1028-330YTR,SRU1028-330YDKR,SRU1028330Y
Standard Package 1,000
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8504.50.4000
Win Source Part Number 1273174-SRU1028-330Y
Ultra Librarian 3D Model Ultra Librarian SRU1028-330Y CAD Model

Description

The SRU1028-330Y is a drum core, wirewound inductor from Bourns Inc. that features a ferrite core material and a shielding design.

  • Inductance: 33 µH
  • Tolerance: ±30%
  • DC Resistance (DCR): 139mOhm
  • Current Rating: 1.25A
  • Saturation Current Rating: 1.2A
  • Temperature Range: -40°C to 125°C
  • Frequency Self-Resonant: 12MHz
  • Mounting: SMD (SMT) technology
  • Package/Case: Nonstandard
  • Category: Inductors, coils, chokes
