Bourns Inc. presents the 1273003-SRU6025A-1R2Y, a drum core, wirewound electronic component from the SRU6025A series. The part number is 1273003-SRU6025A-1R2Y, and the category is inductors, coils, chokes > fixed inductors. The package is tape & reel, and the component is shielded. The inductance is 1.2 μH, and the height-seated (max) is 0.110" (2.80mm). The standard package is 600, and the mounting is SMD (SMT). The tolerance is ±30%, and the ratings are AEC-Q200. The material-core is ferrite, and the Q @ Freq is 8 @ 7.96MHz. The frequency-self resonant is 120MHz, and the package / case is nonstandard. The DC resistance (DCR) is 19mOhm Max, and the supplier device package is -. The temperature range - operating is -40°C ~ 125°C, and the dimension is 0.256" L x 0.244" W (6.50mm x 6.20mm). The MSL level is 1 (unlimited), and the current rating (amps) is 4 A. The inductance frequency-test is 100 kHz, and the REACH status is REACH unaffected. The HTSUS is 8504.50.4000.
