SRU6025A-4R7Y Real Image
Same model may have multiple batches, images only for reference.

SRU6025A-4R7Y

Part No SRU6025A-4R7Y
Manufacturer Bourns Inc.
Catalog Fixed Inductors
Datasheet
SRU6025A-4R7Y Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Inductors, Coils, Chokes>Fixed Inductors
Mfr Bourns Inc.
Series SRU6025A
Package Tape & Reel
Type Drum Core, Wirewound
Material - Core Ferrite
Inductance 4.7 µH
Tolerance ±30%
Current Rating (Amps) 2.7 A
Current - Saturation (Isat) 1.55A
Shielding Shielded
DC Resistance (DCR) 35mOhm Max
Q @ Freq 8 @ 7.96MHz
Frequency - Self Resonant 42MHz
Ratings AEC-Q200
Temperature Range - Operating -40°C ~ 125°C
Inductance Frequency - Test 100 kHz
Mounting SMD (SMT)
Package / Case Nonstandard
Dimension 0.256" L x 0.244" W (6.50mm x 6.20mm)
Height - Seated (Max) 0.110" (2.80mm)
Base Product Number SRU6025A
Other Names SRU6025A-4R7YDKR,SRU6025A-4R7YTR,SRU6025A-4R7Y,SRU6025A-4R7YCT
Standard Package 600
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8504.50.4000
Win Source Part Number 1272997-SRU6025A-4R7Y
Ultra Librarian 3D Model Ultra Librarian SRU6025A-4R7Y CAD Model

Description

The Bourns Inc. SRU6025A series inductor is a surface-mount device that comes in a standard package of 600.

  • Type: Drum core, wirewound
  • Shielding: Shielded
  • Inductance: 4.7 µH
  • Tolerance: ±30%
  • Core Material: Ferrite
  • Q @ Freq: 8 @ 7.96MHz
  • Frequency-Self Resonant: 42MHz
  • DC Resistance (DCR): 35mOhm Max
  • Operating Temperature: -40°C ~ 125°C
  • Dimension: 0.256" L x 0.244" W (6.50mm x 6.20mm)
  • REACH: Unaffected
  • Current Rating: 2.7 A
  • Rated AEC-Q200: True
