ACPL-227-500E Real Image ACPL-227-500E real image570 ACPL-227-500E Real Image1 ACPL-227-500E Real Image2 ACPL-227-500E Real Image3 ACPL-227-500E Real Image4
Same model may have multiple batches, images only for reference.
ACPL-227-500E Real Image ACPL-227-500E real image570 ACPL-227-500E Real Image1 ACPL-227-500E Real Image2 ACPL-227-500E Real Image3 ACPL-227-500E Real Image4
ACPL-227-500E Real Image ACPL-227-500E real image570 ACPL-227-500E Real Image1 ACPL-227-500E Real Image2 ACPL-227-500E Real Image3 ACPL-227-500E Real Image4
Same model may have multiple batches, images only for reference.

ACPL-227-500E

Part No ACPL-227-500E
Manufacturer Broadcom Limited
Catalog Optoisolators - Transistor, Photovoltaic Output
Description OPTOISOLATOR 3KV 2CH TRANS 8SOIC
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Isolators
Manufacturer Broadcom Limited
Packaging Reel - TR
Status Active
Number of Channels 2
Isolation Voltage 3000Vrms
Minimum DC Current Transfer Ratio 50% @ 5mA
Maximum DC Current Transfer Ratio 600% @ 5mA
Switching Turn-On and Turn-Off Time 3μs, 3μs
Rise and Fall Time 2μs, 3μs
Input Type DC
Output Type Transistor
Maximum Output Voltage 80V
Channel Output Current 50mA
Forward Voltage 1.2V
Continuous forward current- Max 50mA
Vce Saturation (Max) 400mV
Temperature Range - Operating -55°C to 110°C
Mounting SMD (SMT)
Case / Package 8-SO
Win Source Part Number 007873-ACPL-227-500E
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Quantity per package 2k pcs
Ultra Librarian 3D Model Ultra Librarian ACPL-227-500E CAD Model

Description

Product Overview

The ACPL-227-500E is an advanced optocoupler that delivers exceptional electrical isolation for demanding applications. It facilitates high-speed data transfer while preventing electrical disturbances in sensitive electronics.

Applications & Projects

  • Power inverter systems
  • Home appliance control
  • Instrumentation and measurement
  • Electrically noisy environments

Features & Benefits

  • Fast signal propagation delay
  • High common mode transient immunity
  • Compact size for design flexibility
  • Excellent isolation voltage ratings

Additional Details

The ACPL-227-500E is ideal for use in applications where reducing noise interference and allowing high-speed data transfer are key requirements. Its design supports reliable performance in electrically noisy settings, enhancing system integrity.
