HCPL-181-00DE Real Image HCPL-181-00DE real image4559 HCPL-181-00DE real image4560
Same model may have multiple batches, images only for reference.
HCPL-181-00DE Real Image HCPL-181-00DE real image4559 HCPL-181-00DE real image4560
HCPL-181-00DE Real Image HCPL-181-00DE real image4559 HCPL-181-00DE real image4560
Same model may have multiple batches, images only for reference.

HCPL-181-00DE

Part No HCPL-181-00DE
Manufacturer Broadcom Limited
Catalog Optoisolators - Transistor, Photovoltaic Output
Description OPTOISO 3.75KV TRANS 4MINIFLAT
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Isolators
Manufacturer Broadcom Limited
Packaging Reel - TR
Status Active
Number of Channels 1
Isolation Voltage 3750Vrms
Minimum DC Current Transfer Ratio 300% @ 5mA
Maximum DC Current Transfer Ratio 600% @ 5mA
Rise and Fall Time 4μs, 3μs
Input Type DC
Output Type Transistor
Maximum Output Voltage 80V
Channel Output Current 50mA
Forward Voltage 1.2V
Continuous forward current- Max 50mA
Vce Saturation (Max) 200mV
Temperature Range - Operating -55°C to 100°C
Mounting SMD (SMT)
Case / Package 4-Mini-Flat
Win Source Part Number 016854-HCPL-181-00DE
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Quantity per package 3k pcs
Ultra Librarian 3D Model Ultra Librarian HCPL-181-00DE CAD Model

Description

The Broadcom Limited 016854-HCPL-181-00DE is a transistor output type electronic component designed for isolator applications.

  • Forward Voltage: 1.2V
  • Channels: 1
  • Isolation Voltage: 3750Vrms
  • Continuous Forward Current-Max: 50mA
  • Package Quantity: 3k
  • Popularity: High
