HCPL-316J-000E Real Image HCPL-316J-000E real image18040
Same model may have multiple batches, images only for reference.
HCPL-316J-000E Real Image HCPL-316J-000E real image18040
HCPL-316J-000E Real Image HCPL-316J-000E real image18040
Same model may have multiple batches, images only for reference.

HCPL-316J-000E

Part No HCPL-316J-000E
Manufacturer Broadcom Limited
Catalog Isolators - Gate Drivers
Description 2.5 Amp Gate Drive Optocoupler with Integrated (VCE) Desaturation Detection and Fault Status Feedback | OPTOISO 5KV 2CH GATE DRIVER 16SO
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Isolators
Manufacturer Broadcom Limited
Packaging Tube
Technology Optical Coupling
Number of Channels 2
Voltage - Isolation 5000Vrms
Common Mode Transient Immunity (Minimum) 15kV/μs
Propagation Delay tpLH / tpHL (Maximum) 500ns, 500ns
Pulse Width Distortion (Maximum) 300ns
Rise / Fall Time 100ns, 100ns
Current - Output High, Low 2A, 2A
Current - Peak Output 2.5A
Voltage - Output Supply 15V ~ 30V
Temperature Range - Operating -40°C ~ 100°C
Mounting Style SMD
Manufacturer Package 16-SOIC
Supplier Device Package 16-SO
Approvals CSA, IEC/EN/DIN, UR
Manufacturer Pack Quantity 45
MSL Level 1 (Unlimited)
Win Source Part Number 1179109-HCPL-316J-000E
Manufacturer Homepage www.avagotech.com
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian HCPL-316J-000E CAD Model

Description

The Broadcom Limited HCPL-316J-000E is a 2-channel, high-speed optocoupler that comes in a 16-SO package.

  • Component: Broadcom Limited HCPL-316J-000E
  • Channels: 2
  • Type: High-speed optocoupler
  • Package: 16-SO
  • Current-Output High/Low: 2A/2A
  • Voltage-Isolation: 5000Vrms
  • Current-Peak Output: 2.5A
  • Common-Mode Transient Immunity (minimum): 15kV/μs
  • Temperature Range: -40°C to 100°C
  • Pulse Width Distortion (maximum): 300ns
  • Propagation Delay tpLH/tpHL (maximum): 500ns/500ns
  • Rise/Fall Time: 100ns/100ns
  • ECCN: EAR99
  • REACH: Unaffected
  • Supply and Demand: Limited
  • Manufacturer Pack Quantity: 45
