HMPS-2822-TR1 Broadcom Limited HMPS-2822-TR1 Real Image HMPS-2822-TR1 real image
Same model may have multiple batches, images only for reference.
HMPS-2822-TR1 Broadcom Limited HMPS-2822-TR1 Real Image HMPS-2822-TR1 real image
HMPS-2822-TR1 Broadcom Limited HMPS-2822-TR1 Real Image HMPS-2822-TR1 real image
Same model may have multiple batches, images only for reference.

HMPS-2822-TR1

Part No HMPS-2822-TR1
Manufacturer Broadcom Limited
Catalog RF Diodes
Description DIODE SCHOTTKY RF 15V 1A MINPAK
Datasheet
HMPS-2822-TR1 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Broadcom Limited
Packaging Reel - TR
Status Active
Diode Type Schottky - 2 Independent
Voltage - Peak Reverse (Max) 15V
Current - Max 1A
Capacitance @ Vr, F 1pF @ 0V, 1MHz
Resistance @ If, F 12 Ohm @ 5mA, 1MHz
Temperature Range - Operating 150°C (TJ)
Case / Package MiniPak 1412
Win Source Part Number 068179-HMPS-2822-TR1
Popularity Medium
Supply and Demand Status Balance
Quantity per package 3k pcs
Ultra Librarian 3D Model Ultra Librarian HMPS-2822-TR1 CAD Model

Description

The Broadcom Limited HMPS-2822-TR1 is a Schottky diode with 2 independent diodes. It has a maximum current of 1A and a peak reverse voltage of 15V. The capacitance of this diode is 1pF @ 0V, 1MHz and the resistance is 12 Ohm @ 5mA, 1MHz. in the open market. The supply and demand status of this component is balanced, and it comes in a package of 3k pcs.
