HSMS-2812-TR1G

Part No HSMS-2812-TR1G
Manufacturer Broadcom Limited
Catalog RF Diodes
Description RF Diode Schottky 20V 3-Pin SOT-23 T/R / DIODE SCHOTTKY GP LN 20V SOT-23
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Broadcom Limited
Packaging Reel - TR
Status Active
Diode Type Schottky - 1 Pair Series Connection
Voltage - Peak Reverse (Max) 20V
Current - Max 1A
Capacitance @ Vr, F 1.2pF @ 0V, 1MHz
Resistance @ If, F 15 Ohm @ 5mA, 1MHz
Temperature Range - Operating 150°C (TJ)
Case / Package SOT-23-3
Win Source Part Number 017052-HSMS-2812-TR1G
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Quantity per package 3k pcs
Family Name HSMS-2812
Introduction Date April 01, 2004
ECCN EAR99
Country of Origin Thailand, Malaysia
Halogen Free Compliant
Estimated EOL Date Obsolete / End of life
Ultra Librarian 3D Model Ultra Librarian HSMS-2812-TR1G CAD Model

Description

The Broadcom Limited 017052-HSMS-2812-TR1G is a Schottky diode.

  • Peak Reverse Voltage: 20V
  • Maximum Current: 1A
  • Capacitance: 1.2pF @ 0V, 1MHz
  • Resistance: 15 Ohm @ 5mA, 1MHz
  • Case/Package: SOT-23-3
  • Applications: Rectification, clipping, and clamping circuits
