PS2715-1-F3-A CEL PS2715-1-F3-A Real Image
Same model may have multiple batches, images only for reference.
PS2715-1-F3-A CEL PS2715-1-F3-A Real Image
PS2715-1-F3-A CEL PS2715-1-F3-A Real Image
Same model may have multiple batches, images only for reference.

PS2715-1-F3-A

Part No PS2715-1-F3-A
Manufacturer CEL
Catalog Optoisolators - Transistor, Photovoltaic Output
Description OPTOISOLATOR 3.75KV TRANS 4SMD
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Isolators
Manufacturer CEL
Packaging Reel - TR
Status Active
Number of Channels 1
Isolation Voltage 3750Vrms
Minimum DC Current Transfer Ratio 100% @ 1mA
Maximum DC Current Transfer Ratio 400% @ 1mA
Rise and Fall Time 4μs, 5μs
Input Type AC, DC
Output Type Transistor
Maximum Output Voltage 40V
Channel Output Current 40mA
Forward Voltage 1.15V
Continuous forward current- Max 50mA
Vce Saturation (Max) 300mV
Temperature Range - Operating -55°C to 100°C
Mounting SMD (SMT)
Case / Package 4-SOP
Win Source Part Number 045933-PS2715-1-F3-A
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian PS2715-1-F3-A CAD Model

Description

The supply and demand status of this product is currently balanced.

  • Product: Isolator
  • Manufacturer: CEL
  • Win Source Part Number: 045933-PS2715-1-F3-A
  • Packaging: Reel - TR
  • Mounting: SMD (SMT)
  • Output Type: Transistor
  • Forward Voltage: 1.15V
  • Input Type: AC, DC
  • Channels: 1
  • Isolation Voltage: 3750Vrms
  • Case/Package: 4-SOP
  • Minimum DC Current Transfer Ratio: 100% @ 1mA
  • Maximum DC Current Transfer Ratio: 400% @ 1mA
  • Switching Turn-On and Turn-Off Time: Not specified
  • Rise and Fall Time: 4μs, 5μs
  • Maximum Output Voltage: 40V
  • Channel Output Current: 40mA
  • Continuous Forward Current-Max: 50mA
