The PS2801-4-F3-A(NL) is a multi-channel solid-state relay (SSR) manufactured by CEL (California Eastern Laboratories). It features four independent channels, allowing for simultaneous switching of multiple signals with galvanic isolation. The 'F3' likely denotes a specific tape and reel packaging for automated assembly, 'A' may indicate a particular pinout or internal configuration, and '(NL)' signifies a lead-free version, compliant with RoHS standards.

Applications

• Industrial Automation: Used in programmable logic controllers (PLCs) and distributed control systems (DCS) for switching multiple inputs/outputs (I/O).
• Data Acquisition Systems: Employed in data loggers and measurement equipment for isolated channel selection and switching.
• Automatic Test Equipment (ATE): Utilized in test fixtures and automated test systems for switching multiple test points.
• Multiplexers: Can be configured as a multiplexer for signal routing and selection in various electronic systems.
• Process Control: Integrated into process control systems for controlling multiple actuators and sensors with isolation.

Features

• Multi-Channel Configuration: Provides four independent SSR channels in a single package.
• High Isolation Voltage: Offers strong galvanic isolation between the input and output circuits for each channel.
• Low On-Resistance: Minimizes voltage drop and power dissipation across the switch.
• Fast Switching Speed: Enables rapid switching operations for improved system response.
• Compact Package: Reduces board space requirements and simplifies circuit design compared to using discrete SSRs.

Benefits

• Simplified Circuit Design: Multi-channel integration reduces component count and simplifies PCB layout.
• Enhanced Safety: High isolation voltage protects sensitive circuits and personnel from hazardous voltages.
• Improved Efficiency: Low on-resistance minimizes power loss, leading to energy savings.
• Increased System Performance: Fast switching speed allows for quick response times and improved control.
• Reduced Costs: Integration and simplified design can lead to lower overall system costs.

Additional Details

The PS2801-4-F3-A(NL) typically operates with a low control input voltage for each channel. It's generally capable of switching voltages up to 60V and currents up to 350mA per channel. The isolation voltage is typically 3750 Vrms. It is RoHS compliant (NL indicating lead-free). The F3 suffix indicates specific tape and reel packaging. The operating temperature range is generally between -40°C and +85°C. Always refer to the specific datasheet for detailed electrical characteristics and application guidelines.
